IC Programmer

Features

IC software copy and program
Product Name IC Programmer
Product Code KM21-11
Weight About 1.8 kg
Voltage AC 110 V ~ 240 VAC, auto switching
Frequent Range 47 ~ 63 Hz
Power Consumption 25 W
Operating Temperature 5 ~ 45。C  (41 ~ 113。F)
Function IC software copy and program
Features
  1. USB or parallel port interface with auto-switch power
  2. Support 5 V and 3.3 V low voltage devices
  3. 1.8 V chip support through low voltage adapter
  4. Less than 2 seconds per Mbit Programming speed for high density flash chip
  5. No adapter required for chip up to 48 pin
  6. 48 pin universal pin driver and current limit
  7. Auto-sense/Self programming with statistical report
  8. Device insertion / continuity check
  9. Universal adapter for 44 pin PLCC/QFP/TQFP/PSOP and 40/48 TSOP
  10. Support OS: Windows 95/98/Me/NT/2000/XP/Vista(32bit)/7(32bit)/8(32bit) etc.
  11. Welcome to inquire with us for more information
